| 01. FRAME | All New, Series 4 Alloy, 160mm MultiTrac Suspension LT, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle |
| 02. FRONT SUSPENSION | Marzocchi Z1, 170mm, 29", 11Oxl 5 Kabolt Thru Axle, 44mm Offset |
| 03. REAR SUSPENSION | Marzocchi CR Coil, 205x65mm, Trunnion Upper Mount, 30xM8 Lower Hardware, Custom Tune, Spring Rate S/M = 350 lbs/in M/L = 450 lbs/in |
| 04. RIM | Front: 29" Diameter, 32mm Inner Rim Width; Rear: 27.5" Diameter, 32mm Inner Rim Width, Tubeless Compatible |
| 05. HUB REAR | Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| 06. HUB FRONT | Shimano FH-TC500, 11 Oxl 5mm, Centerlock, 32H |
| 07. SPOKES | 14g Black Stainless Steel |
| 08. TIRES | Vee Tire Co Attack HPL, E-Control Compound, Front 29x2.5", Rear 27.5x2.5" |
| 09. DERAILLEUR REAR | Shimano CUES SL-U6000-1OR, 1 0-Speed |
| 10. DERAILLEUR FRONT | 0 |
| 11. SHIFT LEVER | Shimano CUES SL-U6000-1OR, 1 0-Speed |
| 12. CRANKSET | e*thirteen e*spec Plus Cranks, 160mm Length |
| 13. MOTOR | Bosch Performance CX, 85Nm |
| 14. CHAIN | Shimano LG500 |
| 15. CASSETTE | Shimano CS-LG300-10, 11-48T |
| 16. BRAKES FRONT | TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick |
| 17. BRAKES REAR | TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick |
| 18. BRAKE LEVERS | TRP Slate EVO |
| 19. HANDLEBAR | Marin Mini Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5° Up, 9° Back |
| 20. STEM | Marin 3D Forged Alloy, 35mm |
| 21. GRIPS | Marin Grizzly Lock On |
| 22. HEADSET | FSA Custom Headset, Adjustable HTA Design |
| 23. SEATPOST | TranzX, YSP39 1 x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| 24. SADDLE | Marin Speed Concept |
| 25. PEDALS | 0 |
| 26. BATTERY | Bosch PowerTube 750 Wh |
| 27. DISPLAY | Bosch BRC3100 Systems Controller |
| 28. SWITCH | Bosch BRC3300 Bluetooth Remote 22.2mm Clamp |
| 29. EXTRAS | e*thirteen e*Spec Chainguide |
| 30. EXTRAS | Cush Core Pro Tire Inserts, Marin Tire Sealant 300ml Bottle |
