Key Performance Factors

Optimal Trail Design

Lightweight ALUXX SL-grade aluminum hardtail frame with a steep seat tube angle optimizes your input when powering up climbs and hammering on the flats, resulting in greater efficiency and speed. And a 66-degree head tube angle offers confidence on steep

Boosted Confidence

Take on technical terrain with the 130mm of plush front suspension, high-volume tubeless tires offering extreme traction on roots, rocks and ruts, and a dropper seatpost allowing you to get low and ride with control.

Adventure-Ready

Equipped with mounts for 2 water bottle cages and a small gear bag on the underside of the top tube for extra tools and snacks. Internal cable routing keeps the important stuff tidy and protected, so you can stay focused on the ride ahead.

Techs & Features

ALUXX Aluminum Technology
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.

Tubeless System
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.

OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

Sizing

Sizing to be used as a reference only and based on rider's height. Please check with us to determine the correct size.

XS (27.5"): 150cm - 163cm
S (27.5"): 158cm - 169cm
S (29"): 158cm - 169cm
M (29"): 164cm - 175cm
L (29"): 170cm - 181cm

Specs

Sizes	27.5": XS, S 29": S, M, L
Colours	Sea Sparkle, Bay Leaf
Frame	ALUXX SL-grade aluminum, 12x148 thru-axle
Fork	Giant Crest 34 RCL, 130mm, 15x110
Shock	N/A
Handlebar	Giant Contact TR35, 20mm rise, alloy 27.5": XS: 760mm, S: 760mm 29": S: 760mm, M: 760mm, L: 780mm
Grips	Liv Sole-O
Stem	Giant Contact SL, 35mm 27.5": XS: 40mm, S: 40mm 29": S: 40mm, M: 50mm, L: 50mm
Seatpost	Giant Contact Switch dropper, remote 27.5": XS: 100mm travel / 30.9 x 345mm, S: 100mm travel / 30.9 x 345mm 29": S: 100mm travel / 30.9 x 345mm, M: 125mm travel / 30.9 x 395mm, L: 150mm travel / 30.9 x 440mm
Saddle	Liv Sylvia
Pedals	platform
Shifters	Shimano CUES SL-6000, 1x10
Front Derailleur	N/A
Rear Derailleur	Shimano CUES RD-U6000, Shadow
Brakes	Tektro HDM 276, hydraulic, Shimano RT-24 rotors [F]180mm, [R]180mm
Brake Levers	Tektro HDM 275 (special edition), hydraulic, Shimano rotors [F]180mm, [R]180mm
Cassette	Shimano CUES CS-LG300, 11x48
Chain	Shimano CUES LG500
Crankset	Shimano CUES, FC-U6000-1, 30t 27.5": XS: 170mm, S: 170mm 29": S: 170mm, M: 170mm, L: 170mm
Bottom Bracket	Shimano, threaded
Rims	27.5": Giant AM 27.5, tubeless ready, sleeve-joint rim, 30mm inner width 29": Giant AM 29, tubeless ready, sleeve-joint rim, 30mm inner width
Hubs	alloy, sealed
Spokes	Sapim
Tires	Minion DHF 27.5x2. 5" WT [F] Dissector 2.4" WT [R]
Extras	27.5": tubeless prepared, max tire size 2.6", max chainring size 32t 29": tubeless prepared, max tire size 2.5", max chainring size 32t
